- Features:
- Stainless Steel 304/316L connections.
- Maximum Operating Pressure 250 PSI (17bar), And Other Working Pressure available.
- Stainless Steel,High Polished Exterior.
- Side Connection or End Connection.
- Smooth & Sleek Look.
- Unique Design saves both Time and Money.
- Competitive Prices.
- Designed fro direct connection to most style of RO Membranes
- Double O-ring.
 |
|
| 4"RO memberane shell series | 8" RO memberane shell series |
 |
|
| Item | A | B | C | DN1 | DN |
| 4021-1 | 595 | 35 | 125 | 15 | 15 |
| 4040-1 | 1090 | 35 | 125 | 15 | 15 |
| 4040-2 | 2106 | 35 | 125 | 20 | 15 |
| 4040-3 | 3122 | 35 | 125 | 20 | 15 |
| 4040-4 | 4138 | 35 | 125 | 20 | 15 |
| 8040-1-B | 1256 | 1086 | 230 | 40 | 25 |
| 8040-2-B | 2272 | 2102 | 230 | 40 | 25 |
| 8040-3-B | 3288 | 3118 | 230 | 40 | 25 |
| 8040-4-B | 4304 | 4134 | 230 | 40 | 25 |
| 8040-5-B | 5320 | 5150 | 230 | 40 | 25 |
| 8040-6-B | 6336 | 6166 | 230 | 40 | 25 |
